20A 25A 30AContact switching capability
Suitable for switching motor load
Dusty construction
PCB and QC terminal available
Outline dimensions30.2×23.3×15.6mm
Contact Parameters
| Contact Arrangement | 1A | |
| Contact Material | Silver Alloy | |
| Contact Resistance (Initial) | ≤100mΩ（1A 6VDC） | |
Rated Load | 20A 277VAC(Resistance) 25A 250VAC(Resistance) 16A 250VAC(Resistance) 30A 250VAC(Resistance) | |
| Max. Switching Current | 30A(Resistance) | |
| Max. Switching Voltage | 250VAC | |
| Max. Switching Power | 7500VA | |
Electrical Life | ≥ 1×105 Ops | |
| Mechanical Life | ≥ 5×105 Ops | |
Characteristics
| Insulation Resistance | 1000MΩ(500VDC) |
Dielectric Strength | Between Coil & Contacts: 4500VAC 1min |
| Between Open Contacts: 1500VAC 1min | |
| Operate Time | ≤15ms |
| Release Time | ≤5ms |
| Ambient Temperature | -40°C ~+105°C |
| Vibration Resistance | 10Hz~55Hz 1.5mm (DA) |
Shock Resistance | Functional: 98m/s²(10G) |
Destructive: 980m/s²(100G) | |
| Terminal Form | MPY: PCB+QC MPY-P: PCB |
| Construction | Dust Protected Sealed |
| Unit Weight | Approx. 23g |
