A relay drive refers to an electronic circuit or system that is used to control a relay. A relay is an electromechanical switch that opens or closes a circuit in response to an electrical signal. The purpose of a relay drive is to amplify a small control signal, typically from a microcontroller or low-power source, to activate a relay that can switch much larger currents needed for high-power applications. Without a relay drive, it would be impossible to directly control such high-power devices with small, low-voltage signals.

    Working Principle of Relay Drive

    At the core of a relay drive system is its ability to amplify a small current and trigger the relay coil to operate the switch. The basic working principle involves the following components：
