Relays are fundamental components in electrical and electronic circuits, offering a reliable means of controlling the flow of electrical power using a low-power signal. Understanding the key relay characteristics is essential for selecting the right relay for your application. In this article, we will explore the various aspects of relay functionality, including coil voltage, contact configuration, switching times, and more, to help you better understand how relays operate and how to choose the correct relay for your needs.
1. Coil Voltage and Coil Resistance
At the heart of a relay is the coil, which is energized to activate the relay’s switch. The coil voltage is the voltage required to energize the coil and cause the relay to operate. This voltage varies depending on the type of relay and is typically available in common ratings such as 5V, 12V, or 24V DC. It is crucial to match the coil voltage with the power supply to ensure proper operation.
The coil resistance determines the current drawn by the relay coil when it is energized. A higher coil resistance results in lower current draw for a given voltage. Understanding the coil resistance is vital for energy efficiency and to avoid overloading the power supply.
